Create an alarm from a DC 09 alarm

🟢 Beginner

alarm

In this tutorial, you will learn how to create an OnSphere alarm from a DC 09 alarm.

Create an action of type CREATE_ALARM that will be called when a matching DC09 event arrives.
Configure an IP-RCT server to receive forwarded alarms from the DC09 gateway.
Define an IP-RCT device matching a specific transmitter identifier.
Create a FIRE_AND_FORGET textual value with an alarm owner that matches NFA alarm codes and links to the action.

git checkout origin/osp-alarms-configuration .
git checkout origin/osp-web-configuration .
git checkout origin/osp-ip-rct-configuration .
git checkout origin/example-alarms-created-from-dc09 .

Prerequisites

Logical schema

Configuration structure

Steps

1. Create an action that can create an alarm

root/alarms/dc09-alarm/action/action.ospp

 {
     "moduleId": ["modules.ip-rct.ip-rct-1"],
     "type": "CREATE_ALARM"
 }

2. Create a server that will communicate with the DC09 gateway dc09.gateway.local

root/alarms/dc09-alarm/gateway/value.ospp

{
    "name": "DC09 Gateway",
    "description": "",
    "type": "BOOLEAN"
}

root/alarms/dc09-alarm/gateway/server.ip-rct

{
    "moduleId": "modules.ip-rct.ip-rct-1",
    "hostname": "dc09.gateway.local",
    "port": 8080,
    "username": "ae-osp-user",
    "passwordProvider": {
        "type": "PLAINTEXT",
        "password": "ae-osp-password"
    },
    "aeIdentifier": "ae-osp"
}

3. Create a device that will match the transmitter D00001

root/alarms/dc09-alarm/device/value.ospp

{
    "name": "DC09 alarm transmitter",
    "description": "",
    "type": "BOOLEAN"
}

root/alarms/dc09-alarm/device/device.ip-rct

{
    "linkedServer": "root.alarms.dc09-alarm.gateway",
    "ipSptIdentifier": "D00001"
}

4. Create a textual value with FIRE_AND_FORGET retention so the value will be treated as an event instead of a state

root/alarms/dc09-alarm/alarm/value.ospp

{
    "name": "Fire alarm",
    "description": "",
    "type": "TEXT",
    "retention": "FIRE_AND_FORGET"
}

5. Create an alarm owner next to the textual value that will match NFAxxxx alarms coming from the D00001 transmitter, and link it to the action created earlier

root/alarms/dc09-alarm/alarm/owner-alarm.ip-rct

{
    "linkedDevice": "root.alarms.dc09-alarm.device",
    "alarmTypes": [
        "ALARM"
    ],
    "criteriaExpression": "^NFA\\d{4}$",
    "linkedAction": {
        "actionId": "root.alarms.dc09-alarm.action",
        "expiration": {
            "value": 4,
            "unit": "SECONDS"
        },
        "parameters": {
            "timestamp": {
                "type": "FIELD",
                "field": "TIMESTAMP"
            },
            "severity": {
                "type": "CONSTANT",
                "value": 600
            },
            "summary": {
                "type": "CONSTANT",
                "value": "Fire alarm"
            },
            "location": {
                "type": "FIELD",
                "field": "CONTENT",
                "fieldParser": "spt.locationAddress"
            },
            "source": {
                "type": "FIELD",
                "field": "CONTENT",
                "fieldParser": "spt.name"
            },
            "serial": {
                "type": "FIELD",
                "field": "ID"
            },
            "tags": {
                "type": "LIST",
                "values": [
                    {
                        "type": "CONSTANT",
                        "value": "DC09"
                    }
                ]
            },
            "additionalData": {
                "type": "PROPERTIES",
                "properties": {
                    "transmitter": {
                        "type": "FIELD",
                        "field": "CONTENT",
                        "fieldParser": "spt.sptIdentifier"
                    }
                }
            }
        }
    }
}
